ST-01100
Automotive Relay
Automotive Relais
Manufacturer: SHENG TENG
Product details
Main Features:
- 60A/80A continuous current capacity
- Automotive-oriented design
- Fully Standardized quick connect size and layout
- Plastic cover for rough environment protection
- with molded bracket
Typical Applications:
- Head lights
- Fog lamp
- Signal horn
- Starter relay
- Radiator cooling fan
- Power window
- ABC system
- Start bypass relay
Product details of ST-01100
Details
| Form | 1 Form A, 4 Pins |
| Max. Switching Current Make | 240A |
| Max. Switching Current Brake | 80A |
| Material | AgSnOlnO |
| Max Continuous Current | 80A |
| Min. Load | 0.1A 12VDC |
| Service Life Mechanical | 10 million ops |
| Service Life Electrical | 100,000ops |
| Ambient Temperature | 40~125°C operating; -40~125°C storage |
| Vibration Resistance | 10-40 Hz: DA 1.27 mm; 40-70 Hz: 5 g;70-100 Hz: DA 0.5 mm; 100-500 Hz: 10 g |
| Shock Resistance | 20 g; 11 ms |
| Dielectric Strength | 500 Vrms; 1 min |
| Drop Resistance | 1 M height drop on concrete |
| Power Consumption | 1.6W, unsuppressed; 1.81W, with resistor |
| Insulation Resistance | 50MΩ (500 VDC) |
| Operating Time | 7 ms typical |
| Release Time | 2 ms typical |
| Weight | 35 g, approx |
